MagnaPower complete ECS sortation syste, with fines capability, 3 KW rotor motor, VFD controls

Details

Description

(1) Vibratory Feeding Bin
(1) Trommel Screen

(1) PMDS Magnapower Drum Magnet (Ferrous Removal)
(1) Rubber Belt Transfer conveyor.
(2) Vibratory feeders.
(1) Eccentric Super-Fines Magnapower Eddy Current Separator:
Non-deteriorating rare earth (neodymium) permanent magnet system.
Field anti-leakage material increasing performance up to 50%.
Cantilever frame for simple belt change and maintenance.
Eccentric rotor offers greater reliability & Magnapower's design offers greater effective area, closer material to field tolerances, and optimal pole to rotor diameter ratio.
3kW Rotor Motor (3 Phase / 60 Cycle / 460 Volts).
1.5kW Belt Motor (3 Phase / 60 Cycle / 460 Volts).
VFD controls
Belt cleaning brush
Adjustable splitter box and frame.
Labyrinth bearing seals to protect rotor and bearings.
The Magnapower Eddy Current Separator (ECS) is suitable for a wide range of applications from the recovery of small non ferrous metals 2mm in size and above (fines) to larger shredded scrap metal processes.
* Available in standard and "super-fines" ECS configurations (Pricing varies).
** Available with optional MAGSTAR high intensity sorter.
***Quote And Video References 600mm Wide ECS Belt Width.
